8011 and 3105 aluminum foil for bottle cap can be used as the raw material of anti-counterfeit aluminum bottle caps. Aluminium foil for bottle caps can be divided into casting and hot rolling. Bottle caps aluminium foil also has different tempers such has H16 and H18, which can satisfy the requirements of different industries.
Aluminum sheet for bottle caps 3105/8011 is of light weight, superior barrier property, plasticity and good decoration.
The Specification of Aluminium Foil For Bottle Cap:
Alloy | 8011/3105 Aluminum Alloy |
Temper | H14, H16, H18, H24, H26, H44, H46 |
Thickness | 0.15-0.45mm |
Type | Sheet/Coils/Foils/Strips |
Surface Treatment | Aluminum surface is treated by phosphorous chromate and DOS oil treated. |
Application | Caps, closures and vials for the pharmaceutical industry. Closures ‘pilfer proof’ for the pharmaceutical industry. Lids and containers for the cosmetics industry. |
MOQ | 1-3 ton per specification |
Packaging | Export wooden stronger boxes |
Delivery Time | 25-30 days |
Chemical Composition of 8011 3105 Bottle Cap Aluminium Foil(%):
Alloy | Fe | Si | Cu | Mn | Mg | Cr | Zn | Ni | Ti | Other | Al |
8011 | 0.60~1.0 | 0.50~0.9 | 0.1 | 0.2 | 0.05 | 0.05 | 0.1 | - | 0.08 | 0.15 | Remain |
3105 | 0.7 | 0.6 | 0.3 | 0.3~0.8 | 0.2~0.8 | 0.2 | 0.4 | - | 0.1 | 0.15 | Remain |
The Properties of Aluminium Foil For Bottle Caps:
Mechanical Property for CC Materials of Aluminium Foil for Bottle Cap | ||||||
Alloy | Temper | Thickness (mm) | U.T.S (Mpa) | Elongation (%) | Earring Rate | |
8011 | H14 | 0.16~0.23 | 185~205 | >=2 | <2% | |
Mechanical Property for DC Materials of Aluminium Foil for Bottle Cap | ||||||
Alloy | Temper | Thickness (mm) | U.T.S (Mpa) | Elongation (%) | Earring Rate | |
8011 | H14 | 0.16~0.23 | 125~155 | >=2 | <2% | |
The Advantages of Aluminum Foil For Bottle Cap:
1, Stable mechanical properties and good earing , less than 2% steadily or no ears for parts.
2, Good plasticity capable of drawing deepth, at most 75mm,free of "orange peel" after stamping.
3, Better surface quality and uniform fine lines.
4, High thickness precision, up to +0.005mm.
The Application of Bottle caps Aluminium Foil:
Range from screw caps for whiskey and other beverage bottles to aluminum closures for wine bottles. ROPP cap material can be ordered as rolled, degreased, pre-lubed, pre-treated or lacquered.
The cap material process has to go through a number of processes such as hot rolling - cold rolling - annealing - dos oil lubrication -coating - printing- slitting - quality check- packaging, etc.
Wine bottle caps, medical caps, cosmetic caps, soft drink/juice/isotonic/energy beverage caps, cosmetic caps, can caps, vial seals caps, tear off seal caps, flip-off vial seals, aluminium closures, pharmaceutical caps, pull-off aluminum cap, injection vial caps, injection bottle caps.
8011/3105 aluminum sheet will be packed by wooden pallet with net weight 0.8-1 ton per each pallet.There are styles of packaging, which is eye to wall or eye to sky. Customers can choose either of them for their convenience.
Plastic movie and brown paper can be protected at customers’ need. Also timber case or timber pallet is adopted to shield products from harm for the duration of the delivery.
20’ GP FCL can full-load 20 tons by putting 2 layers of pallets of products.
